P900-2250 Dual Frequency

The P900-2250-45 (Dual Frequency) sonar system combines the power of BlueView’s medium range P900 navigation and inspection sonar with the identification capabilities of a higher frequency 2.25 MHz sonar head.

The P900-2250-45 provides both the medium and ultra-short range imaging required to perform complex tasks in zero visibility conditions. The P900-2250-45 is completely compatible with other BlueView ProViewer sonar making integration seamless for existing customers

900 kHz Sonar

• Field of View (°): 45 x 20
• Max Range: 100 m (328 ft.)
• Optimal Range: 2 - 60 m (6.5 - 196.8 ft.)
• Beam Width (°): 1 x 20
• Number of Beams: 256
• Beam Spacing (°): 0.18
• Range Resolution: 1 in.
• Update Rate (Hz): Up to 15
• Frequency (kHz): 900

   2.25 MHz Sonar

• Field of View (°): 45 x 20
• Max Range: 8 m (26.2 ft.)
• Optimal Range: 0.5 - 5 m (1.6 - 16.4 ft.)
• Beam Width (°): 1 x 20
• Number of Beams: 256
• Beam Spacing (°): 0.18
• Range Resolution: 0.4 in.
• Update Rate (Hz): Up to 15
• Frequency (MHz): 2.25

   Interface

• Voltage (V DC): 12-48
• Power Consumption (24VDC):
• 900kHz - 31 W - 15.5 W (Min - Max Range)
• 2250KHz - 31 W - 24.5 W (Min - Max Range)
• Coms: Ethernet

   Mechanical

• Weight in Air (lbs.): 6.0
• Weight in Water (lbs.): 1.5
• Depth Rating: 300 m (1,000 ft.)
• Size (L x maximum OD in inches): 8.3 x 5.0
